Features of HCH2-1300 High Speed Slitting Machine with Friction Shaft

USE:
This type high speed slitting machine is the ideal processing machine for high demand of speed and precision.

It is applicable to PE, PP, PET, PVC and other plastic film, paper, composite film, aluminum film, color film, all kinds of adhesive tape and label.

It is the ideal model of film,thin film processing and color printing company especially electronic products and up-market boutique packaging products.

Characteristic:
This roller slitting machine adopted slip shaft based on the model HCH1-1300 high speed slitting machine,which can achieve the perfect fixing for different kinds of materials rewinding,can reduce the cost waste occurred because of the irregular rewinding,slitting cutoff,off-roller.

Two servo motors independently control the unwinding and 2 pcs slip shafts rewinding,can insure the tension more better,rewinding smoothly and slitting accurately.

Slip shaft of the specific role is as follows: Slip shaft is used to slitting the rewinding product tension, the slip shaft above the slip ring will be based on the size of each roll of different sizes of materials, rolling, The difference will be through the shaft with the slippage, to achieve a balanced effect of tension and stability, and finally the performance of the finished product in the rounded out of the neat, tight moderate, a good solution to the shortcomings of the air shaft (face irregular, Very loose, some too tight deformation). At the same time, the slip bearing is significant, the maximum shaft can reach 60, the smallest also has 50. Under normal circumstances, for the weight of more than 200 kg, the need for the appropriate assembly of a feeder, in the protection of the slip shaft is not only easy deformation of the case, but also to facilitate the operation of workers, a person can operate a slitter.

PLC
Unwind
Transmission
Knife
Rewind
Trimmed waste
  • 1
    Touch screen on Human machine interface (HMI)
  • 1
    Air shaft
  • 2
    Ultrasonic rectification is adopted detect the rectification of rolling
  • 3
    Pneumatic powder brake
  • 4
    Tension automatic controlled by PLC
  • 1
    The material of rubber covered roller use polyurethane (wearproof)
  • 2
    Aluminum rod after Hardness oxide (protection materials and scratch-proof)
  • 3
    The movement of rubber covered roller is controlled by the cylinder
  • 4
    Servo motor and Main machine is of variable-frequency drive
  • 5
    Synchronous belt
  • 1
    Shear cutter system (sharp, flexibleand slitting efficiently)
  • 2
    Automatic metering
  • 1
    Slip shaft
  • 2
    Electronic proportional valve
    PLC automatic add and subtract
  • 1
    Equipped with blower and expulsion tube

Specifiction HCH2-1300 High Speed Slitting Machine with Friction Shaft

Optional: Rewind web clamping, Splicing table, Laser core position, Automatic loading system, Hydraulic lift up, Dual rewind sations, Dual unload station

Technical parameter:

Model

HCH2-1300

Max.  Unwinding width

1300mm

Total power

13kw

Speed

300~400m/min

Precision

±0.03mm

Unwinding roller diameter

∮1000mm

Rewinding roller diameter

∮2*600mm

Machine weight

3000kg
