HCH3-1300R2/1700R2 Paper Film Double Shaft Rewinding Machine

It applies to rewind paper, paperboard, silicon coated paper, non woven cloth and packaging materials.
To get an instant quote Now
Application Features Specification Video

Application

Paper

Offset paper

Thermal paper

Paperboard, thickness can reach to 1mm and more,

Sublimation transfer paper

Large format roll paper for inkjet prints, HP wide-format matte canvas paper roll

Weatherproof poster paper

      √ Engineering copier bond plotter paper rolls

Film

Optical film

Protective film

Heat transfer film gold silver hot stamping foil rolls

Waterproof inkjet film for silk screen printing

Vinyl PVC

Adhesive Material

Reflective film for traffic signs, road signs, street signs, custom signs

Self adhesive paper and film

Protective film

√ Adhesive Vinyl Roll for Cricut, Silhouette and Other Cutters, Permanent Outdoor Vinyl for Decor Sticker, Car Decal, Scrapbooking,Signs, Glossy & Waterproof

Features

3"+6" shaft less loading

● 3”+6“  mechanical chuck

● Automatic shaft less loading

● Automatic left and right movement

● Automatic hydraulic loading

SIEMENS PLC

● Germany SIEMENS PLC automatic control, mature program

● Friendly operation

Autonics metering control

● Korean Autonics brand automatic metering, assure high precision meter counting

4 sets servo motor control

● 1 set servo motor control the traction

● 2 sets servo motor independently control 2 rewinding, let 2 rewinding shaft independent

running, while the machine runs, the operator can unload finished rolls and reload cores in preparation for the next running cycle

● 1 set high precision servo motor control the turret section, ensure that the rewinding shaft is positioned in the correct position so that the material can be properly attached to the rewinding core.Turreted rewinder is ideal for reducing downtime and increasing throughput in a converting operation. While the machine runs, the operator can unload finished rolls and reload cores in preparation for the next running cycle

Option:

Automatic cut-off and transfer

Packaging section

Automatic pushing for finished product

Automatic box up-ender

Automatic egde trimming

Specification

Technical Parameter

Machine model

HCH3-1300R2

HCH3-1700R2

Unwinding width

1300mm

1700mm

Machine speed

300m/min

300m/min

Precision

±0.03mm

±0.03mm

Unwinding diameter

Φ1200mm

Φ1200mm

Rewinding diameter

2*Φ200mm

2*Φ200mm

Main servo motor power

4KW

4KW

Rewinding servo motor power

5.5KW×2

7.5KW×2

Installation dimension

3000*2750*1550mm

3000*3150*1550mm

Machine weight

3700kg

4200kg
