It is suitable for the transverse cutting of the reel material after printing. This machine is a specialist for horizontal and vertical cutting paper rolling materials to A4, A3, A2 size. Get a Quote for A4 paper cutting machine, A3 paper cutting machine, A2 guillotine machine price to Us NOW!
| Machine model | LY-C1100B |
Max unwinding diameter | φ1400mm |
Reference weight of cutting paper | 40~500g |
Max cut width | 1100mm |
Cutting length | 20-1000mm |
Cutting speed | 150-160 times/min |
Cutting precision | ±0.2mm |
Voltage: | AC380V/220V x 50HZ |
Total power | 10KW |
Main function | 1) can be 1 roll,2roll,4 rolls loading (Optioanal) |
2) With paper stacker (include) | |
3) With round cutter for slitting (include) | |
4）With belt transferring (include) |
This A4 paper roll cutting machine adopts down-up recurrent cutting with orderly finished products and without water caltrop. Meanwhile, it can be used for horizontal cutting and vertical cutting at one time;
This roll to A4 paper cutting machine adopts servo motor for controlling constant-length cutting;
This A4 paper cutting machine adopts PLC control, contact screen operation;
This A3 paper cutting machine adopts pneumatic, displacement sensor for controlling transmission system, with photoelectric and gas together, it is of easy operation, high precision, good stability, low noise;
This A2 paper guillotine machine has the frequency converter timing device, automatic counting, stop working by alarm ,magnetic powder tension control, can be vertically, adopt blower fan to get rid of waste;
High-precision of cutting and high speed. Pneumatic structure combined with computer control is adopted for transmission section ,making it much more steady operation;
Automatic stacking and Photoelectric auto tracing subtense system.
Raloyal mission is :To creat and provide value to customers .
So as a enterprise with the strong sense of responsibility .
Raloyla can give the commiment to cusotmer :we provide not only 1 year gurantee ,but also lifelong service support .
The support included :Machine setup &trainning and the parts supply.
For the machine setup ,Customer have 2 ways to choose after receive the machine .
1: Raloyal provide the machine operation video ,drawing, manual etc to customer ,
Most customer have learned the operation well via these information.
2 : Raloyal arrange the service techincan to customer factory for machine set up and trainning .
No matter which way customer choose ,we can also creat a group (advised :wechat ),which will put service technican and the sales in ,in addition , the company CEO will also be there . which means when the operator have any doubt or question for the operation ,they can leave message to the group ,our service technician will reply it as soon as they saw it .
By the way ,we also upload the machine operation video in webiste ,the link path is :
https://www.lyslitter.com/engineering/slitter-machine-operation-video/
For the parts supply ,Raloyal promisie we will provide customer the machine parts (Raloyal machine ) for lifelong time ,which means any time you need part ,we are here .
and provide the part at cost price .
Raloyal ,your loyal partner.
