HCH3-1300B Slitting Machine with Automatic Unloading

Name: HCH3-1300B Slitting Machine with Automatic Unloading
Brand: RUIAN LOYAL MACHINERY CO., LTD.

This type of high-speed slitting machine, also known as a slitter, is the most suitable machine for high-speed and precision demand of the jumbo roller material slitting and rewinding. It is versatile and can be used for various applications such as: release paper, label stickers, label-printing, self-adhesive tape, cardboard ,electronic optical film, release film, electric screen protective film, PET film,lithium battery film , capacitor diaphragm, and coils etc. slitting and rewinding.

To get an instant quote Now

Features Application Our Diffirence Video FAQ Case Share

Features

This machine is with special design, satisfying the demands of jumbo roll, high speed and huge loading weight. Can be equipped with high quality adhesive label and paper, etc. material slitting and rewinding.

Characteristic:

· Automatic unloading device, increase productivity and ensure production safety.
· Automatic shaft-less loading for the jumbo roll.
· Machine driven by 3 sets 11kw servo motors, big power, high precision.
· Double “S” material path to avoid the gum leaking.
· Overhead material path to prevent the gum dripping.
· Machine body processing by CNC, ensure the whole machine precision and stability.
· Solve the problem of the snake shape of the finished product surface.
· Double-bead duplex friction shaft adopted.
· Waste suction device.
· Finished product automatic unloading (option)

Application

The HCH3-1300B slitting machine is a design, especially for the jumbo label /paper roll slitting and rewinding, also can be used for the flexible film, such as PET, BOPP, laminated film etc. film slitting and rewinding.
Release Liners (Paper/ Film) and Label Stocks. Our range consists of Release Paper Liners, Release Film Liners, Self Adhesive Paper Label Stocks (Cromo Art, Maplitho, Mirror Coat, Flourocent paper,Thermal Transfer, Aluminium foil paper( golden and silverl ), pvc film label stocks, vinyl film label stocks, polyester film label stocks, Self Adhesive Film Label Stocks (Polyster Film (metalized/Clear), PVC Film(Color/ Transparent), Vinyls(Colour/Transparent) and Specialty Adhesive Tapes / Label stocks.

Application industry:

Our HCH3 type slitting machines are widely used in label, paper packing, printing, medical, electric and new energy, etc. industry.

Our Diffirence

HCH3-B serious is our latest innovation, owning the excellent performance:

·Automatic unloading device, increase the productivity and ensure the production safety.

·Automatic shaft-less loading for jumbo roll .

·Machine driven by 3 sets 11kw synchronous servo motors, big power, high precision.

·Double“S” material path to avoid the gum leaking.

·Overhead material path to prevent the gum dripping.

·Machine body processing by CNC ,ensure the whole machine precision and stability.

·Solve the problem of snake shape of finished product surface.

·Double-bead duplex friction shaft adopted.

·Semi-auto blade set. (option)

Technical parameter:

1	Machine model	HCH3-2000B	HCH3-1600B
2	Paper range	30-400gsm	30-400GSM
3	Slitting effective width	50-2000mm	50-1600mm
4	Slitting speed	300m/min	300m/min
5	Unwinding roll diameter	φ1200mm	φ1200mm
6	Rewinding roll diameter	2*φ800mm (max bearing weight 400kgs)	2*φ600mm (max bearing weight 500kgs)
7	Main motor power	11kw	11kw
8	Rewinding motor power	2*15kw	2*11kw
9	Total power	45kw	35kw
10	Power supply	380V,3phases, 50hz	380V,3phases, 50hz
11	Machine precision	±0.03mm	±0.03mm
12	Machine weight	7500kg	6700kg
13	Machinedimension	470038002250mm	470035002250mm

Video

FAQ

1: Can it rewind on 6 inches core friction shaft?

Yes, it can.

2: What is the min width for the unwind roll

600mm

3: Is this machine with automatic unload?

Yes. Exactly.

4: Auto push included?

Yes.

5: What kind of container need for delivery?

40 feet container.

6: How about the machine installation and operation when. Machine delivery to our factory?

Machine as usual is integrated and we do not dismantle before delivery.

So just connect the power cable and air pipe is ok.

For the operation, we take instruction video for all customers before delivery to guide you how to operate, and provide the instruction file.

Also, we provide service: our engineer and technician open live training until you learned it and run it well.

7: How about the guarantee?

Ø 12 months guarantee, life-long time technic maintenance and support. 24 hours feedback when receive the client writing militance proposal.

Ø Any part damage caused by non-human factors within the warranty period can be replaced for free, excluding machine consumable parts. Maintenance of part damage caused by violation operation or mis-operation of operators will be charged with costs of parts.

Ø The price of spare parts exceeding the warranty period shall be the lowest ex-factory price of the seller.

Ø For extra accessories beyond the standard configuration of contractual machine, the price shall be the lowest ex-factory price of the seller.

Any time you have question about slitter, we are always here to provide service.

Case Share

The first time for theHCH3 slitting machine showing in public is on the LABELEXPO ASIA 2019 SHANGHAI, though the first time showing, it attracted most visitors’ eyes.

The bright color, the tall and straight body, plus the perfect slitting and rewinding effect, make the vistors stop by and come in our stand.

Our customer from Pakistan at that time found us and ourslitter machine, we left each other name card, they asked us to send quote before leaving, the price also satisfied them much and they dispatched their representative in China office to make trial and discuss after the exhibition, which is closer for the deal conclusion.

The covid-19 pandemonic suddenly came and disrupted the whole plan, but it does not stop the determination of our Pakistan customer to buy the HCH3 slitter.

So client firmly place the order to us on April of 2021, which shows the strongly trust for the future of our slitter slitting.

Now the machine is in running in our customer factory and now they plan the next one.

The dialogue below for your reference.

By now, the machine HCH3-B series machine have sold more than 30 sets both in overseas market and China domestic market .There is a good news we want to share is :: we will launch the updated version –600m/min type very soon ,stay tuned !
