HCH3-1300 High Speed Slitting Machine with Shaftless Unwinding

This PLC Control High Speed Slitting Machine is ideal for all types of the high demand for speed and precision, especially electronic and optical film.
To get an instant quote Now
HCH3-1300 High Speed Slitting Machine with Shaftless Unwinding
This machine is the new design to meet clients high speed and precision inquiry. With PLC, slip shaft, shaftless and automatic loading.

  • APFE2024 2024-03-13 Date:3-5 June 2024
    ​Address: Room 1017 Cao'an International Mart, Building 1855 Cao'an Road, Shanghai China
    ​https://www.apfechina.com/en/​​​​
  • LABELEXPO SOUTH CHINA 2024 2024-03-13 DATA: 4 - 6 DECEMBER 2024
    Address:SHENZHEN WORLD EXHIBITION & CONVENTION CENTER
    ​https://www.labelexpo-southchina.com/
  • LABELEXPO EUROPE 2025 2024-03-13 Date: 16 - 19 September 2025
    Address: FIRA BARCELONA GRAN VIA
    ​www.labelexpo-europe.com
  • LABELEXPO MEXICO 2025 2024-03-13 Date: 1-3 April 2025
    Address: EXPO GUADALAJARA, GUADALAJARA
    www.labelexpo-mexico.com​ ​
Features Machine System SPECIFICTION

FEATURES_OF HCH3-1300 High Speed Slitting Machine with Shaftless Unwinding

USE:
This high-speed slitting machine is high precision and high sensitivity. It has the highest configuration, saving time and effort. Not only achieve high-quality products but also to achieve large-scale production.

It is the ideal model of up-market boutique packaging products, electronic products, film, thin film processing and color printing company.

Release Liners (Paper/ Film)  and Label Stocks. Our range consists of Release Paper Liners, Release Film Liners, Self Adhesive Paper Label Stocks (Cromo Art, Maplitho, Mirror Coat, Flourocent paper,Thermal Transfer, Aluminium foil paper( golden and silverl ), pvc film label stocks, vinyl film label stocks, polyester film label stocks, Self Adhesive Film Label Stocks (Polyster Film (metalized/Clear), PVC Film(Color/ Transparent), Vinyls(Colour/Transparent)  and Specialty Adhesive Tapes / Label stocks.

Characteristic:
This roller slitting machine plus a motor based on HCH2-1300 high speed slitting machine, which can better control the rewinding.Double shaft cantilever structure with independent drive adopted can release of the labor force, save time and effort.Hydraulic lifting shaftless loading to achieve automatic feeding, which can solve the problem of tube deformation, improve efficiency greatly. Slitting faster and more accurately.

The function and working principle of shaftless unwinding chuck are as follows:

In the process of large diameter and large width material feeding, the raw material volume and weight are very large. If you use the airshaft feeding, a certain size of the air shaft may not be able to bear the weight of the material, resulting in airshaft bending and core deformation. that influence the products affectedof after slitting, resulting in the waste of materials.

The tension of the unwinding material is controlled by the pneumatic brake, the pneumatic brake is the use of air pressure to make the movement of mechanical parts to stop or slow down the mechanical parts. The pneumatic brake is more accurate than magnetic powder clutch, better control of unwinding tension.

During the feeding process, the operator can put the material on the cart. Pushed to the front of the machine, the feeding frame down, after the installation of the material up the material rack up. Large volume and weight of the material in the handling process is likely to cause injury, the use of the shaftless automatic feeding system can greatly saving labor, saving time. Safe and convenient operation.

PLC
Unwind
Transmission
Knife
Rewind
Unload
Trimmed waste
Loading
  • 1
    LCD colorful touch screen.
    Dialogue parameter setting environment.     Parameters memory function.    Tension computes function.
    Unwind end roll and web break auto detects and stop function.    Meter reached auto stop function.    Upper and lower rewind shaft different winding direction function.      Rewind tension taper function.
  • 1
    Shaftless unwinding chuck
  • 2
    Ultrasonic rectification is adopted detect the rectification of rolling
  • 1
    the material of rubber covered roller use polyurethane (wearproof)
  • 2
    Aluminum rod after Hardness oxide (protection materials and scratch-proof)
  • 3
    The movement of rubber covered roller is controlled by the cylinder
  • 4
    Servo motor and Main machine is of variable-frequency drive
  • 5
    Synchronous belt
  • 1
    Shear cutter system (sharp, flexibleand slitting efficiently)
    top and bottom knives
  • 2
    Automatic metering
  • 1
    Slip shaft meet different materials’ rewinding
  • 2
    Electronic proportional valve is adopted to control the tension
  • 3

    Dual rewind sations

  • 1
    Dual unload stations and automatic unloading
  • 1
    Equipped with blower and expulsion tube
  • 1
    Automatic loading system
    Hydraulic lift up

SPECIFICTION HCH3-1300 High Speed Slitting Machine with Shaftless Unwinding

Optional: Rewind web clamping, Splicing table, Laser core position

Technical parameter:

Model

HCH3-1300

Max.  Unwinding width

1300mm

Total power

24kw

Speed

300~400m/min

Precision

±0.03mm

Unwinding roller diameter

∮1200mm

Rewinding roller diameter

∮800mm

Machine weight

7000kg

Machine overall dimension

4200*3000*2100mm
