Jumbo Paper Roll High Speed Rotary Knife Sheet Cutting Machine

This series of servo-controlled paper sheeting machine is specialist for processing jumbo rolls of packing material into required size, such as carton, paper board,chrome paper,laser paper, kraft paper,printing paper, gold,silver,alu foil paper, laminated
To get an instant quote Now
  • FAQ 2024-11-05 1:Surface coil slitting how to control rewinding tension?The rewinding shaft is pressed on the roller for slip rewinding, and the pressure can be controlled by a precision pressure regulating valve2:W...
  • Latest Innovation 2024-11-05 What is the latest innovation of RALOYAL ? RALOYAL is always committed to the Research and Development of the technology. In the past years, Raloyal has developed the innovations, including: 1: Automa...
  • Raloyal will participate in the LABELEXPO SOUTH CHINA 2024 2024-11-04 We are glad to announce :Raloyal will participate in the LABELEXPO SOUTH CHINA 2024 at Shenzhen World Exhibition & Convention Center on 4th- 6th Dec.Raloyal will show the latest innovation of :4 ...
  • Features 2024-09-14 This machine is more suit for the high demand of raw material slitting. Such as electronic protective film, optical film and other high-quality tapes, etc.Characteristic:HCH3 series slitting machine a...
Features SPECIFICTION

FEATURES_OF Jumbo Paper Roll High Speed Rotary Knife Sheet Cutting Machine

Use of Automatic High Speed A4/A3 Paper Roll to Sheets Cutting Machine
This series of servo-controlled semi paper cutting machine is specialist for processing jumbo rolls of packing material into required size, such as carton, paper board,chrome paper, laser paper, kraft paper,printing paper, gold, silver, alu foil paper, laminated paper, etc. It is widely used in paper processing and printing packing.

Main Features of A4 Paper Sheeting Machine with Paper Ream Wrapping Pack
  • Automatic roll unwinding unit is equipped with hydraulic shaftless roll stands two clamps and braking system, which are easy-to-use during roll manipulations;
  • Adopts FAG Original imported bearings;
  • Adopts JAPANESE CKD proportional valve;
  • This paper roll slitter rewinder adopts ITALY PHASE servo motor for controlling constant-length cutting;
  • It adopts GERMANY KEB servo drivers;
  • It adopts Simens PLC control, keeps the whole equipment's program and circuit control stable and runs without accident;
  • This automatic rotary type servo driven paper sheeting machine adopts 45 mm heavy-duty steel body to ensure smooth operation and long service life;
  • This 4 roll jumbo roll sheeter adopts Switzerland EHRE timing belt;
  • This roll paper slitter rewinder has the functions of high speed, can reach 300 cuts/min;
  • Conveyor belt adopts Holland Rapplon Belt;
  • Once the machine's program is set, the roll diameter does not need to be adjusted again, reducing manual effort.

Specifiction Jumbo Paper Roll High Speed Rotary Knife Sheet Cutting Machine

Technical Parameter

MachineModel

LY-H1400

LY-H1700

LY-H1900

Reference weight of cutting paper

50-500g/m2

50-500g/m2

50-500g/m2

Diameter of paper

(Can be 1 roll,2roll,4 rolls loading )

1 roll1800mm

1800mm

1800mm

2 roll 1800mm

1800mm

1800mm

4 rolls 1600mm

1600mm

1600mm

Width of paper

1400mm

1700mm

1900mm

Total power

23KW

25KW

27KW

Cutting length

400-1600mm

400-1600mm

400-1600mm

Cutting accuracy

+/-0.2mm

+/-0.2mm

+/-0.2mm

Maximum cutting speed

300cuts/min

300cuts/min

300cuts/min

Maximum cutting meter speed

300m/min

300m/min

300m/min

Atmospheric pressure

0.8MPa

0.8MPa

0.8MPa

Power supply

AC380V/220Vx50HZ

AC380V/220Vx50HZ

AC380V/220Vx50HZ

Total weight

9000kg

10000kg

12000kg

Dimensions

9m×3.9m×2.35m

9m×4.2m×2.35m

9m×4.4m×2.35m
